Aluminum Copolymer Lamination Tape

FOB Reference Price:Get Latest Price
US $2.3-3.8 / Kilograms | 1 Ton/Tons Customer requirements (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Tianhong
Model Number:
Polymer coated Aluminum Tape
Type:
Insulation Tape
Material:
PE
Application:
High Temperature
Rated Voltage:
min 1KV
Tensile Strength:
min 20Mpa
Thickness:
150u-600u
Width:
17mm-600mm
ID:
2.1in / 3.0in / 4.0in / 5.9in(53.5mm / 76mm / 102mm / 150mm)
OD:
500mm-900mm
Length:
1000m-2050m
Color:
Silver/Green/Blue
Supply Ability
Supply Ability:
200 Ton/Tons per Month Customer requirements
Packaging & Delivery
Packaging Details
1.Carton,Then put on a plywood pallet
2. Inner-plastic bag,Outside-carton,Then put on a plywood pallet
Port
Shanghai
Lead Time :
Within 15 days after deposit

Specifications

1.Widely used in electronics, electrical, telecommunication
2.ISO and SGS certificate
3.Base material: aluminum foil

1.Application

1.For optical cable,telephone cables, telecommunication cable

2.Used as waterproof materials

3.For cable shielding

4.Widely used in electronics, electrical, telecommunication

5.ISO and SGS certificate
6.Base material: aluminum foil



2.Specifications

Thickness, length and width can according to customer requorements.

Name

Single side Co-Polymer coated Aluminum Tape

Thickness

150µ-600µ

Width

17mm-600mm

ID(inner diameter)

53.5mm / 76mm / 102mm / 150mm

(2.1in / 3.0in / 4.0in / 5.9in)

ID material

Plastic or Metal

OD(outer diameter)

500mm-900mm

Length

1000m-2050m

Color

Silver/Green/Blue

Packaging

1.Carton,Then put on a plywood pallet

2. Inner-plastic bag,Outside-carton,Then put on a plywood pallet



Name

Double side Co-Polymer coated Aluminum Tape

Thickness

200µ-600µ

Width

17mm-600mm

ID(inner diameter)

53.5mm / 76mm / 102mm / 150mm

(2.1in / 3.0in / 4.0in / 5.9in)

ID material

Plastic or Metal

OD(outer diameter)

500mm-900mm

Length

1000m-2050m

Color

Silver/Green/Blue

Packaging

1.Carton,Then put on a plywood pallet

2. Inner-plastic bag,Outside-carton,Then put on a plywood pallet



S.NO.

Item

Unit

Requirement

1

Appearance



The surface is plain, smooth, uniform.

2

Tensile Strength

Mpa

≥50

3

Break Elongation

%

≥15

4

Bond Strength between steel tape and plastic film

N/cm

≥6.13

5

Cutting Strength of Heal Seal of Plastic Clad Steel tape



Damage between coating and steel tape, no cutting damage between heat seal area of coating

6

Heat Seal Strength of Plastic Clad Steel Tape

N/cm

≥17.5

7

Water Tolerance(68±1°C,168h)Bond Strength

N/cm

≥6.13

8

Jelly Resistance(68±1°C,168h)



No separation between steel tape and pastic film

9

Corrison Resistance(0.1mol/L HCI,480h)

Grade

≥7

10



Dielectric Strength

One-sided Plastic Clad

Steel Tape 1kV, DC, l min.



Without Breakdown

Two –seded Plastic Clad

Steel Tape 2kV, DC, 1 min



Without Breakdown



3.Test report and test machine



Width

(mm)
Thickness

(mm)
Tension

(N)
Tensile strength

(MPa)
Elongation at break

(%)
28.0000.25474.6467.26821.088



test-machines









4.Production line: Paster & Cutting

aluminium tape machine



5.Product pictures

107-8



Silver

IMG_7434





IMG_7433





Blue



IMG_8067



Blue color







GreenGreen (1)



6.Packaging photos

a. Inner-Kraft paper,Then put on a plywood pallet

Packaging-Co-polyer



b. Inner-plastic bag,Outside-carton,Then put on a plywood pallet

8-25



7.Warehouse

IMG_8073



8.Application to Cables

-(3)



9.Certificate:We have ISO,Supply SGS,Certificate of original,MSDS,Test report,ect

ISO-SGS

10.Sample: We are manufacturer,We supply free sample,But please pay express fee.
